SS Heat Exchanger Tube Supplier for Boilers and Condensers
EFFICIENT LONG-LASTING HEAT TRANSFER HEAT EXCHANGER TUBES
As a leading Stainless Steel Heat Exchanger tube manufacturer in India, Eramets Steel Alloys Pvt. Ltd manufactures seamless, welded and U bends tubes for refineries, power plants, and the chemical industry. Our tubes are manufactured as per ASTM A213, A249, A269, A688 and the ASME Boiler and Pressure Vessel Code. Thus our tubes would directly fit into your shell and tube heat exchangers, condensers, feedwater heaters and boilers.
We take pride in the fact that our tubes are engineered for heat transfer efficiency, corrosion resistance and long service life. Close dimensional tolerances and smooth tube walls help resist fouling of the equipment and help heat transfer equipment operate longer between shutdowns.
HEAT EXCHANGER TUBES FOR BOILERS AND CONDENSERS AND PROCESS HEAT EXCHANGERS
We provide seamless and welded alternatives for your heat exchanger tube needs.
Seamless Heat Exchanger Tubes (ASTM A213)
Seamless Heat Exchanger Tubes are produced from the cold draw or pilgering of solid hollows to the final size and solution annealed. This removes the weld seam and results in uniform strength around the entire circumference of the tube. They are recommended for use in high pressure boilers and other critical services.
Welded Heat Exchanger Tubes (ASTM A249/A688)
Welded Heat Exchanger Tubes are produced by automatic TIG welding of strip, resulting in a cold worked weld bead with a structure very close to the parent metal. They also have good wall thickness tolerance and a smooth surface for better heat transfer. Compared to Seamless Heat Exchanger Tubes, they are less expensive, and thus are used in condensers, feedwater heaters and HVAC systems.
| Factor | Seamless Tubes | Welded Tubes |
|---|---|---|
| Pressure and temperature |
Higher | Moderate to high |
| Wall thickness accuracy |
Good | Excellent |
| Cost | Higher | Lower |
| Long lengths | Limited by drawing | Very long lengths possible |
| Typical use | Boilers, refineries, critical service | Condensers, feedwater heaters, HVAC |
Stainless Steel Heat Exchanger Tubes
U-Bends provide greater freedom for thermal expansion and contraction of the tube bundle and are therefore used in feedwater heaters, steam generators and some types of shell and tube exchangers with a single tube sheet. We supply U-bend tubes as per specifications of ASTM A213, A249 and A688 in seamless and welded condition [confirm in-house U-bending].
U-Bends are formed with controlled wall thinning and ovality. On special requests, stress relief or solution annealing of the bent portion of the U-tube is carried out, and the tubes are hydrostatically tested after bending. The tubes are supplied row-wise, tagged and packed in sturdy wooden cases. This ensures that the tubes reach the customer’s shop ready for assembly.
Stainless Steel Heat Exchanger Tube Specifications
Our facilities enable us to meet most industrial requirements for heat exchangers, condensers and boilers.
| Parameter | Specification |
|---|---|
| Outside diameter | 6 mm to 101.6 mm |
| Wall thickness | 0.70 mm to 8.0 mm |
| Length | Up to 30 metres, cut lengths and U-bends |
| Type | Seamless, welded, U-bend |
| Surface finish | Bright annealed, annealed and pickled, mechanical polished, electropolished |
| Ends | Plain end, square cut, deburred, capped |
| Documents | Mill Test Certificate EN 10204 3.1 / 3.2 |
Heat Exchanger Tube Standards (It is in Table Formate)
| Standard | Description |
|---|---|
| ASTM A213 / ASME SA213 | Seamless ferritic and austenitic alloy steel boiler, superheater and heat exchanger tubes |
| ASTM A249 / ASME SA249 | Welded austenitic steel boiler, superheater, heat exchanger and condenser tubes |
| ASTM A269 | Seamless and welded austenitic stainless steel tubing for general service |
| ASTM A688 / ASME SA688 | Welded austenitic stainless steel feedwater heater tubes, including U-tubes |
| ASTM A270 | Seamless and welded austenitic stainless steel sanitary tubing |
| EN 10216-5 | Seamless stainless steel tubes for pressure purposes |
| EN 10217-7 | Welded stainless steel tubes for pressure purposes |
| BS 3059 | Steel boiler and superheater tubes |
Types of Available Material
We manufacture and supply heat exchanger tubes of various corrosion-resistant alloys (confirm which materials are manufactured in-house).
| Material | Grades |
|---|---|
| Stainless steel | 304, 304L, 316, 316L, 321, 347, 310S, 317L, 904L |
| Duplex and super duplex | 2205 (UNS S31803 / S32205), 2507 (UNS S32750) |
| Nickel alloys | Inconel, Monel, Hastelloy |
| Copper alloys | Cu-Ni 90/10, Cu-Ni 70/30 |
| Titanium | Grade 1, Grade 2, Grade 5 |
| Carbon steel | ASTM A179, ASTM A210 |
Heat Exchanger Tube Manufacturing Range
| Tube OD | Wall thickness | Maximum length |
|---|---|---|
| 6 mm – 12.7 mm | [0.70 – 1.65 mm] | Up to 30 m |
| 15.88 mm – 25.4 mm | [0.89 – 2.77 mm] | Up to 24 m |
| 31.75 mm – 50.8 mm | [1.24 – 3.40 mm] | Up to 18 m |
| 63.5 mm – 101.6 mm | [1.65 – 8.0 mm] | Up to 12 m |
Custom sizes and lengths are available on request.
Surface Finish Options
| Finish | Best for |
|---|---|
| Bright annealed | Clean internal surface, general heat exchangers |
| Annealed and pickled | Chemical and petrochemical service |
| Mechanical polished | Hygienic and decorative applications |
| Electropolished | Pharmaceutical and food processing |
| UHP (Ultra High Purity) | Semiconductor and ultra-clean systems |
How to Choose the Right Heat Exchanger Tube Grade
The main factors that determine the grade of tube we use are the fluids on the shell and tube side, chloride content of the fluid and the operating temperature. Use the table below for a general idea and our engineers will confirm the actual grade for your design.
| Service condition | Commonly used grade |
|---|---|
| Fresh water, steam, mild chemicals | SS 304L |
| Cooling water with chlorides, food and pharma | SS 316L |
| High-temperature service | SS 321, SS 347, SS 310S |
| Risk of chloride stress corrosion cracking | Duplex 2205 |
| Seawater and brine | Super Duplex 2507, Titanium Grade 2, Cu-Ni 90/10 |
| Sulphuric and phosphoric acid service | SS 904L |
Our Process as Stainless Steel Heat Exchanger Tube Manufacturer in India
Heat exchanger tubes have to withstand heat, pressure and corrosion so we manage all stages of production.
1. Raw Material Check – Hollows and strips are examined for chemistry and heat and traceability.
2. Forming – Seamless tubes are pilgered and cold drawn and welded tubes are roll formed and TIG welded.
3. Solution Annealing – Stainless steel tubes are bright annealed and full annealed and pickled to restore full corrosion resistance.
4. Straightening and Cutting – Tubes are straightened and cut to length. U-bends are made where required.
5. Testing – Non-destructive tests, hydrostatic test, dimensional and mechanical tests are done as per the order standards.
6. Marking and Packing – Each tube is marked with its grade, size, standard and heat number and then capped and packed.
Quality Testing and Inspection
Each of Eramets Steel Alloys Pvt. Ltd.’s heat exchanger tubes is thoroughly tested, including the following:
– Hydrostatic pressure testing
– Eddy current testing, ASTM A1016
– Ultrasonic testing
– Positive Material Identification (PMI)
– Chemical composition analysis
– Tensile testing and hardness testing
– Flattening, flaring, and flange testing
– Reverse bend test for welded tubes
– Intergranular corrosion test (ASTM A262) upon request
– Surface roughness test
A Mill Test Certificate is included with each shipment, and 3.1 and 3.2 certification by an independent third party is available upon request.
Heat Exchanger Tube Operating Temperature
The safe operating temperature of a heat exchanger tube varies with grade and wall thickness and is related to the design code and the pressure for which it was designed. Stainless steels, such as 304L and 316L, retain their toughness at temperatures as low as -196 °C. Stabilized grades, such as 321 and 347 and heat-resisting grades, such as 310S are chosen for high temperature services. Allowable stresses at design temperatures are given in ASME Section II. Please share your design temperature and pressure and we will suggest an appropriate grade.
Stainless Steel Heat Exchanger Tube Weight Chart
| OD (mm) | Wall thickness (mm) | Weight (kg/m) |
|---|---|---|
| 9.53 | 1.00 | 0.21 |
| 12.70 | 1.20 | 0.34 |
| 15.00 | 1.00 | 0.35 |
| 19.05 | 1.65 | 0.71 |
| 25.40 | 1.65 | 0.98 |
Weight is calculated for austenitic stainless steel (density about 7.93 g/cm³) and formula is : Weight (kg/m) = (OD − WT) × WT × 0.0249. For other sizes, please use our weight calculator.
Heat Exchanger Tube Applications
| Industry | Application |
|---|---|
| Oil and gas, refineries | Process heat exchangers, coolers, reboilers |
| Chemical and petrochemical | Heat transfer in corrosive process streams |
| Power plants | Condensers, feedwater heaters, boilers |
| Pharmaceutical | Sterile process tubing, WFI systems |
| Food, dairy and beverage | Hygienic heat exchangers, pasteurisers |
| Desalination | Brine heaters and condensers |
| HVAC and refrigeration | Chillers and cooling systems |
Types of Heat Exchanger Tubes We Supply
| By form | By material and use |
|---|---|
| Straight heat exchanger tubes | Stainless steel heat exchanger tubes |
| U-tube heat exchanger tubes | Duplex and super duplex heat exchanger tubes |
| Seamless heat exchanger tubes | Titanium heat exchanger tubes |
| Welded heat exchanger tubes | Copper-nickel heat exchanger tubes |
| Finned heat exchanger tubes | Condenser tubes |
| Corrugated heat exchanger tubes | Boiler tubes |
Packing and Export Documentation
Every tube is shipped protected with end caps and bundled for easy transport. For oversized tubes, protection is provided with seaworthy wooden cases. As an SS heat exchanger tube supplier to global projects, we understand the necessity for documentation for your tubes to pass customs unimpeded and for site inspection. As such, Mill Test Certificates, packing lists, certificate of origin, and third-party inspection reports are provided as required.
Supply Across India and Export Markets
We supply stainless steel heat exchanger tubes to refineries, power plants, and process industries located in Mumbai, Delhi, Ahmedabad, Pune, Hyderabad, Chennai, Bangalore, Kolkata, and other industrial cities in India.
Our export clients are in the UAE, Saudi Arabia, Qatar, Oman, Vietnam, Thailand, Indonesia, Nigeria, Kenya, the Netherlands and other countries.
Why Choose Eramets Steel Alloys Pvt Ltd
Some of the major reasons for Eramets Steel Alloys Pvt. Ltd. being chosen as the stainless steel heat exchanger tubes manufacturer in India are:
· In-house manufacturing of seamless, welded, and U-bend tubes.
· ISO 9001:2008 certified quality system
· Tubes in conformity to ASTM, ASME, EN and BS standards.
· Complete testing and Mill Test Certificates for every consignment.
· Ready stock of many sizes and grades.
· Competitive prices for bulk orders and projects.
· Export packaging and all related documents.
Eramets Steel Alloys Pvt Ltd is a trusted manufacturer, exporter, and global supplier of stainless steel heat exchanger tubes in India, delivering premium quality tubing solutions for high-performance industrial heat transfer systems. With advanced manufacturing facilities and strict quality control processes, we produce heat exchanger tubes that meet and exceed international standards such as ASTM A213, ASTM A269, ASTM A249, and the ASME Boiler and Pressure Vessel Code.
Our stainless steel heat exchanger tubes are designed to deliver maximum thermal efficiency, high corrosion resistance, and long operational durability, making them ideal for demanding industrial environments. Manufactured using high-grade raw materials and precision engineering techniques, our tubes provide excellent mechanical strength, superior internal surface finish, and outstanding resistance to high temperatures and pressure conditions.
Stainless Steel Heat Exchanger Tube Manufacturer & Exporter in India
At Eramets Steel Alloys Pvt Ltd, we supply high-precision heat exchanger tubing for condensers, boilers, shell and tube heat exchangers, and process equipment used across major industries including chemical processing, petrochemical plants, oil refineries, power generation facilities, pharmaceutical manufacturing units, food processing industries, and HVAC systems.
Our commitment to innovation, quality assurance, and international manufacturing standards ensures that every product we deliver provides efficient heat transfer performance, reduced energy consumption, and long service life, making us a preferred partner for industrial buyers, EPC contractors, and global distributors seeking reliable stainless steel heat exchanger tube solutions.
Stainless Steel Heat Exchanger Tube Specifications
Our manufacturing range covers a wide variety of industrial requirements.
Parameter | Specification |
Outside Diameter | 6 mm to 101.6 mm |
Wall Thickness | 0.70 mm to 8.0 mm |
Length | Up to 30 meters |
Manufacturing Type | Seamless / Welded |
Surface Finish | Bright Annealed / Electropolished / Mechanical Polished |
Standards | ASTM, ASME, EN, DIN |
These specifications ensure high strength, smooth internal surface finish, and efficient heat transfer performance.
Heat Exchanger Tube Standards
Our products comply with major international standards including:
Standard | Description |
ASTM A213 | Seamless ferritic and austenitic alloy steel boiler tubes |
ASTM A269 | Stainless steel seamless and welded tubes |
ASTM A249 | Welded austenitic steel tubes for boilers |
ASTM A270 | Sanitary stainless steel tubing |
EN 10216 | European pressure tubes standard |
BS 3059 | British standard for boiler tubes |
Compliance with these standards guarantees global industrial acceptance and reliability.
Available Material Grades
We manufacture heat exchanger tubes in several corrosion-resistant alloys.
Material | Grades |
Stainless Steel | 304, 304L, 316, 316L, 321, 347 |
Nickel Alloys | Inconel, Monel, Hastelloy |
Copper Alloys | Cu-Ni 90/10, Cu-Ni 70/30 |
Titanium | Grade 1, Grade 2, Grade 5 |
Carbon Steel | ASTM A179, ASTM A210 |
These materials provide excellent resistance to high temperatures, pressure, and corrosive environments.
Other Types of Heat Exchanger Tubes
| Heat Exchanger Tubes | Heat Exchanger Tubes |
|---|---|
| Straight Heat Exchanger Tubes | U-Tube Heat Exchanger Tubes |
| Finned Heat Exchanger Tubes | Corrugated Heat Exchanger Tubes |
| Tube Bundle Heat Exchanger Tubes | Seamless Heat Exchanger Tubes |
| Welded Heat Exchanger Tubes | Stainless Steel Heat Exchanger Tubes |
| Duplex Steel Heat Exchanger Tubes | Super Duplex Heat Exchanger Tubes |
| Copper Heat Exchanger Tubes | Brass Heat Exchanger Tubes |
| Titanium Heat Exchanger Tubes | Alloy Steel Heat Exchanger Tubes |
| Condenser Heat Exchanger Tubes | Boiler Heat Exchanger Tubes |
Heat Exchanger Tube Manufacturing Range
Tube OD | Thickness | Length |
12 mm | 1.0 mm | Up to 30 m |
19 mm | 1.65 mm | Up to 24 m |
25.4 mm | 1.65 mm | Up to 24 m |
38 mm | 2.0 mm | Up to 18 m |
50 mm | 3.0 mm | Up to 12 m |
This wide range enables customization for various industrial applications.
Surface Finish Options
Our heat exchanger tubes are available in multiple finishes depending on application.
Finish Type | Application |
Bright Annealed | Clean internal surface |
Electropolished | Pharmaceutical & food industry |
Annealed & Pickled | Chemical industry |
Mechanical Polished | Decorative & hygienic applications |
UHP Utility | Ultra hygienic systems |
Heat Exchanger Tube Applications
Our stainless steel heat exchanger tubes are widely used across multiple industries.
Industry | Application |
Chemical Industry | Heat transfer systems |
Oil & Gas | Refinery heat exchangers |
Power Plants | Condenser tubes |
Food Industry | Hygienic heat exchangers |
Pharmaceutical | Sterile process tubing |
HVAC | Cooling systems |
These industries require high performance tubing capable of operating under extreme conditions.
Heat Exchanger Tube Operating Temperature
Temperature Range | Value |
Minimum Temperature | −100°C |
Maximum Temperature | 600°C |
This wide temperature capability makes our tubes suitable for cryogenic as well as high temperature environments.
Quality Testing and Inspection
All products supplied by Eramets Steel Alloys Pvt Ltd undergo strict quality testing procedures.
Testing includes:
- Ultrasonic Testing
- Chemical Composition Analysis
- Mechanical Strength Testing
- Hardness Testing
- Flattening Test
- Surface Roughness Inspection
Each product is supplied with Mill Test Certificate (EN 10204 3.1 / 3.2).
Heat Exchanger Tube Weight Chart
OD (mm) | Wall Thickness | Weight (kg/m) |
25.4 | 1.65 mm | 0.95 |
19.05 | 1.65 mm | 0.71 |
15 | 1.0 mm | 0.43 |
12.7 | 1.2 mm | 0.48 |
9.53 | 1.0 mm | 0.25 |
This chart helps engineers calculate heat exchanger tube bundle weight and installation load.
Export Countries
We export stainless steel heat exchanger tubes worldwide including:
- United Arab Emirates
- Saudi Arabia
- Qatar
- Oman
- Vietnam
- Thailand
- Indonesia
- Nigeria
- Kenya
- Netherlands
Supply Locations in India
Our stainless steel heat exchanger tubes are supplied across major industrial cities:
- Mumbai
- Delhi
- Ahmedabad
- Pune
- Hyderabad
- Chennai
- Bangalore
- Kolkata
Why Choose Eramets Steel Alloys Pvt Ltd
✔ ISO certified manufacturer
✔ Global export supply network
✔ Custom manufacturing capability
✔ Large ready stock
✔ Competitive factory pricing
✔ International quality standards
Our commitment to quality and reliability makes us a trusted supplier for industrial heat exchanger tube solutions worldwide
